When working with Databricks pipelines and workflows, failures are inevitable. While Databricks provides built-in notifications for job failures, these alerts are often not customizable and may not fit specific reporting or formatting needs. A more flexible and cost-effective approach is to set up custom email notifications that include pipeline details and error messages in a structured format, such as an Excel attachment.

This blog walks through approaches to implement custom notifications using SMTP, SendGrid, Azure Logic Apps, and Microsoft Graph API.

Why Custom Notifications?

Flexible formatting: Include pipeline metadata, error messages, and runtime details.
Attachments: Share structured reports (Excel, CSV, etc.) instead of plain text.
Cost efficiency: Avoid additional third-party monitoring solutions.
Integration options: Easily plug into existing email infrastructure.

Approach 1: SMTP-Based Notifications

Using SMTP with Python inside a Databricks notebook, you can generate an Excel report and send it via email whenever a pipeline fails.

Example Implementation

import smtplib
from email.mime.multipart import MIMEMultipart
from email.mime.base import MIMEBase
from email.mime.text import MIMEText
from email import encoders
from io import BytesIO
import pandas as pd

#Sample pipeline history
df = spark.createDataFrame([ ('pipeline1', 'success', '7min'), ('pipeline1', 'fail', '3min'), ('pipeline1', 'success', '10min') ], ["PipelineName", "Status", "Duration"])

# Convert DataFrame to Excel
output = BytesIO()
with pd.ExcelWriter(output, engine='xlsxwriter') as writer:
df_pd = df.toPandas()
df_pd.to_excel(writer, index=False, sheet_name='Sheet1')
workbook = writer.book
worksheet = writer.sheets['Sheet1']

# Apply formatting
header_format = workbook.add_format({
    'bold': True,
    'bg_color': '#FFF00',
    'border': 1,
    'align': 'center',
    'valign': 'vcenter'
})
for col_num, value in enumerate(df_pd.columns):
    worksheet.write(0, col_num, value.upper(), header_format)

cell_format = workbook.add_format({'border': 1})
for row in range(1, len(df_pd) + 1):
    for col in range(len(df_pd.columns)):
        worksheet.write(row, col, df_pd.iloc[row-1, col], cell_format)

for i, col in enumerate(df_pd.columns):
    worksheet.set_column(i, i, 20)
output.seek(0)

# Email configuration
sender = "[email protected]"
receiver = "[email protected]"
subject = "Pipeline Execution Report"
body = """Hello Team,

Please find the attachment of the latest pipeline report.

Thanks,
Pipeline Team"""

msg = MIMEMultipart()
msg['From'] = sender
msg['To'] = receiver
msg['Subject'] = subject
msg.attach(MIMEText(body, 'plain'))

part = MIMEBase('application', 'vnd.openxmlformats-officedocument.spreadsheetml.sheet')
part.set_payload(output.read())
encoders.encode_base64(part)
part.add_header('Content-Disposition', 'attachment; filename="pipeline_report.xlsx"')
msg.attach(part)

smtp_server = "smtp.office.com"
smtp_port = 587

with smtplib.SMTP(smtp_server, smtp_port) as server:
    server.starttls()
    server.login(sender, "sender_password")
    server.send_message(msg)

print("Email sent successfully with Excel attachment")

Scheduling Notifications

You can automate the notification trigger by scheduling the notebook:

Option 1: Databricks Jobs

Create or edit a Databricks job.
Add a task dependency so the notification script runs only if the previous task fails.
This ensures error details are captured and reported immediately.

Option 2: Azure Logic Apps

Configure a Logic App that listens for pipeline failures.
Pass pipeline details and attachments via an API call in JSON format.
Logic Apps handle email delivery and retry mechanisms.

Conclusion

While Databricks provides basic failure notifications, extending them with custom SMTP or Logic App workflows ensures:

Rich, formatted reports.
Team visibility with detailed context.
Seamless integration with enterprise communication tools.

This approach is cost-effective, scalable, and easily adaptable for large-scale pipeline monitoring.
