Most beginners understand “threads”, but they struggle to visualize how multithreading works in Spring Boot.
It goes deeper into why, how, internals, threading concepts, performance behavior, and production considerations.

Why Do We Need Multi-Threading in Spring Boot?

In a typical Spring Boot application, each incoming HTTP request is handled by a Tomcat worker thread.
This thread

Everything happens inside one thread unless you explicitly decide to go async.

This becomes a problem when your request needs to perform slow operations, such as

The Tomcat thread is blocked → slow API → low throughput.

Doing them one-by-one makes your API slow.

Sequential Execution = Slow

Task A → Task B → Task C
Total time = A + B + C

But many of these tasks can run in parallel.

Parallel Execution = FAST

Task A
Task B
Task C
(run at the same time)

Imagine a Real Story

Your API needs to gather user information

If you do this sequentially

2 + 3 + 4 = 9 seconds

Users will assume your API is broken.

But notice these calls have no dependency on each other.

So, they can run in parallel

Run all 3 calls together → total time = 4 sec (longest task)

This is exactly what ExecutorService + CompletableFuture helps you achieve.

What Are ExecutorService & CompletableFuture?

ExecutorService

Think of it like a worker team.

CompletableFuture

A Future on steroids

Visual Explanation — How it Works

Without Parallelism (Sequential)

[API Call]
     |
     |--> Task 1 (3 sec)
     |--> Task 2 (2 sec)
     |--> Task 3 (5 sec)
Total = 10 seconds

With Multithreading (Parallel)

[API Call]
     |
     |--> Task 1 (3 sec)
     |--> Task 2 (2 sec)
     |--> Task 3 (5 sec)
All run at same time
Total = 5 seconds (longest task)

Architecture Diagram

How Multi-Threading Actually Works Internally

Let’s break this down in extremely simple terms.

Step 1: Spring Boot receives a request

A Tomcat thread (say Thread #27) picks it up.

Step 2: Tomcat thread delegates async tasks to ExecutorService

ExecutorService is a thread pool.

Think of it like

“Here are 5 workers (threads). They will do tasks for you.”

You submit tasks:

executor.submit(taskA)
executor.submit(taskB)
executor.submit(taskC)

Now 3 worker threads run tasks in parallel.

Tomcat thread is free to do other work.

Step 3: CompletableFuture wraps tasks to run async

CompletableFuture is like a promise

So,

CompletableFuture<String> orders = service.fetchOrders();

...means
“Start task orders now and return response immediately.”

Step 4: allOf() waits until all threads complete

This is a synchronization point

CompletableFuture.allOf(orders, payments, shipment).join();

This says
“Combine results only when ALL futures have completed.”

Step 5: Tomcat thread collects results and sends response

By the time Tomcat thread gathers results, tasks are already done.

Result →

Difference Between Thread, ExecutorService & CompletableFuture (Very Clear)

Concept

Meaning

Analogy

Thread

Lowest unit of execution

One worker

ExecutorService

A pool of reusable threads

A team of workers

CompletableFuture

Async task handler, easy API

A promise that work will finish

Why Not Create Threads Manually?

Because manual threads cause:

ExecutorService manages threads properly:

CompletableFuture adds additional magic:

Together → powerful and clean async code.

Real Spring Boot Code

Step 1(a): Create Thread Pool Bean

@Configuration
public class AsyncConfig {

    @Bean
    public ExecutorService executorService() {
        return Executors.newFixedThreadPool(5);
    }
}

Meaning

This is crucial for performance.

Step 1(b): Parallel Tasks Using CompletableFuture

return CompletableFuture.supplyAsync(() -> {
    sleep(3000);
    return "Result A";
}, executor);

Breakdown

This ensures your tasks do not run on the main request thread.

Step 2: Service using CompletableFuture

@Service
public class AggregationService {

    private final ExecutorService executor;

    public AggregationService(ExecutorService executor) {
        this.executor = executor;
    }

    // Simulate a remote call or IO-bound work
    public CompletableFuture<String> fetchOrders() {
        return CompletableFuture.supplyAsync(() -> {
            sleep(300);
            return "OrdersLoaded";
        }, executor);
    }

    public CompletableFuture<String> fetchPayments() {
        return CompletableFuture.supplyAsync(() -> {
            sleep(250);
            return "PaymentsLoaded";
        }, executor);
    }

    public CompletableFuture<String> fetchShipment() {
        return CompletableFuture.supplyAsync(() -> {
            sleep(500);
            return "ShipmentLoaded";
        }, executor);
    }

    private void sleep(long ms) {
        try {
            TimeUnit.MILLISECONDS.sleep(ms);
        } catch (InterruptedException e) {
            Thread.currentThread().interrupt();
        }
    }
}

Step 3: Controller — Run all tasks in parallel

@RestController
@RequestMapping("/api")
public class AggregationController {

    private final AggregationService service;

    public AggregationController(AggregationService service) {
        this.service = service;
    }

    // Endpoint using CompletableFuture + custom ExecutorService
    @GetMapping("/aggregate")
    public String aggregate() {
        Instant start = Instant.now();

        CompletableFuture<String> orders = service.fetchOrders();
        CompletableFuture<String> payments = service.fetchPayments();
        CompletableFuture<String> shipment = service.fetchShipment();

        // Wait for all to complete
        CompletableFuture.allOf(orders, payments, shipment).join();

        String result = orders.join() + " | " + payments.join() + " | " + shipment.join();

        Instant end = Instant.now();
        long elapsedMs = Duration.between(start, end).toMillis();
        return String.format("result=%s; elapsedMs=%d", result, elapsedMs);
    }}

Meaning
“Wait until all async tasks finish.”

Then collect results

String result = orders.join() + " | " + payments.join() + " | " + shipment.join();

This is done only when all tasks complete.

What Happens When You Call / Aggregate?

Orders = 3 sec
Payments = 2 sec
Shipment = 5 sec

All run simultaneously.

Total time = 5 seconds (longest task)

Without parallelism → 3 + 2 + 5 = 10 seconds
With parallelism → only 5 seconds

Output

Performance Comparison

Scenario

Execution Time

Sequential Processing

10 sec

Parallel Processing (3 tasks)

4 sec

Parallel + non-blocking I/O

2–3 sec

This is a 60% to 80% performance boost.

Real-World Production Scenarios

Here are real use cases where multi-threading is used in enterprise applications:

Aggregating Microservice Results

User Profile API → 2 sec
Orders API → 3 sec
Payments API → 1 sec

Parallel makes response time 3 seconds instead of 6.

Data Engineering

Spark-like parallel job in Spring Boot:

ExecutorService is ideal here.

Large Report Generation

A PDF report may contain:

Each section can be calculated in parallel.

AI/ML Feature Generation

Extract:

These can run independently → perfect for threads.

Sending Multiple Notifications

Your system triggers:

All can run asynchronously.

Thread Safety Considerations (Important for Interviews)

When using multi-threading

Spring beans are singletons, so ensure they don’t store per-request state.

Scaling Considerations

Thread pool size depends on workload:

For CPU-bound tasks

threads = number of CPU cores + 1

For IO-bound tasks

threads = 2 × cores or even higher

Danger - Too many threads

Always benchmark thread pool sizes.

Advantages of Using ExecutorService + CompletableFuture

Massive performance improvement → Parallelism reduces wasted time.

Non-blocking architecture → Allows server to handle more requests.

Clear async syntax → Very readable.

Built-in error handling → Computation doesn’t silently fail.

Thread pooling for efficient usage → No thread explosion.

Works with Microservice Aggregation pattern → Modern microservices use this everywhere.
