This is not an article delving into the details of AWS Secrets Manager or SSM Parameter Store, but a quick overview of how to use them to store secrets like API keys as I did in this project.

https://github.com/avr2002/files-api/tree/main?embedable=true

AWS Secrets Manager

AWS Secrets Manager helps you to securely store, rotate, and manage sensitive information like API keys, database credentials, OAuth tokens, and other secrets. Instead of hardcoding credentials in your application code, you can store them in Secrets Manager and retrieve them programmatically during runtime when needed.

Secrets Manager provides several benefits:

Pricing

AWS Secrets Manager Pricing page.

Setting up Secrets Manager in CDK

When creating secrets in AWS Secrets Manager using AWS CDK, it is recommended to avoid hardcoding the secret value directly in the CDK code. This is because the secret value will be included in the output of the CDK synthesis process and will appear in the CloudFormation template, which can lead to security risks.

The recommended approach is to create the secret without specifying the secret value in the CDK code. After deploying the stack, you can manually add the secret value in the Secrets Manager console. Secrets Manager will automatically create a placeholder or empty secret for you during deployment.

Here is an example of how to create a simple plain-text secret in Secrets Manager using CDK and grant read permissions to a Lambda function:

import aws_cdk as cdk
from aws_cdk import (
    Stack,
    aws_lambda as _lambda,
    aws_secretsmanager as secretsmanager,
)
from constructs import Construct

class MyCDKStack(Stack):

    def __init__(self, scope: Construct, construct_id: str, **kwargs) -> None:
        super().__init__(scope, construct_id, **kwargs)

        # Create a new secret in Secrets Manager
        my_super_secret_api_key = secretsmanager.Secret(
            self,
            id="SuperSecretApiKey",
            description="Super secret API key for my Lambda function",
            secret_name="my-app/super-secret-api-key",
            # secret_string_value=...,
            # ^^^AWS discourages to pass the secret value directly in the CDK code as the value will be included in the
            # output of the cdk as part of synthesis, and will appear in the CloudFormation template in the console
            removal_policy=cdk.RemovalPolicy.DESTROY,
        )
        # ^^^The recommended way is to leave this field empty and manually add the secret value in the Secrets Manager console after deploying the stack.
        # AWS Secrets Manager will automatically create a placeholder/empty secret for you
        # The secret exists in AWS, but initially has no value (or a generated random value depending on the context).

        # This way, the secret value never appears in code, outputs, or CloudFormation templates.

        # Create a Lambda function that uses the secret
        my_lambda = _lambda.Function(
            self,
            id="MyLambdaFunction",
            function_name="my-lambda-function",
            runtime=_lambda.Runtime.PYTHON_3_12,
            architecture=_lambda.Architecture.ARM_64,
            handler="lambda_function.lambda_handler",
            code=_lambda.Code.from_asset("lambda"),
            environment={
                "SUPER_SECRET_API_KEY_NAME": my_super_secret_api_key.secret_name
            }
        )

        # Grant the Lambda function permission to read the secret
        my_super_secret_api_key.grant_read(my_lambda)

Accessing secrets in AWS Lambda

There are multiple ways to access secrets within an AWS Lambda function. In all the cases, you need to mindful of Secrets Manager costs of $0.05 per 10,000 API calls to retrieve secrets.

  1. Using boto3 SDK API calls to fetch the secret from Secrets Manager.

    • This is straightforward.
    • You need to handle caching of the secret to avoid fetching it on every invocation, managing retries, and error handling for API calls.
    import boto3
import json
import os
from botocore.exceptions import ClientError

# Global variable to cache the secret after the initial retrieval
_CACHED_SECRET: str | None = None

def get_secret():
    """Retrieves the secret from Secrets Manager, with in-memory caching."""
    session = boto3.session.Session()
    client = session.client(service_name='secretsmanager', region_name="us-west-2")

    try:
        get_secret_value_response = client.get_secret_value(SecretId="my-app/super-secret-api-key")
    except ClientError as e:
        # Handle exceptions such as ResourceNotFoundException
        raise e

    # Decrypts secret using the associated KMS key.
    if 'SecretString' in get_secret_value_response:
        return get_secret_value_response['SecretString']
    else:
        # Handle SecretBinary if necessary (e.g., decode base64)
        raise ValueError("SecretString not found, SecretBinary not implemented in this example")

def lambda_handler(event, context):
    # Retrieve the secret (uses cache if available)
    global CACHED_SECRET

    # This will only fetch the secret once during the first invocation
    if CACHED_SECRET is None:
        CACHED_SECRET = get_secret()
        os.environ["MY_API_KEY"] = CACHED_SECRET

    # ... DO STUFF WITH THE SECRET ...

    return {
        'statusCode': 200,
        'body': json.dumps('Secret retrieved and used successfully!')
    }

  2. Use the AWS-Parameters-and-Secrets-Lambda-Extension to securely fetch secrets inside the Lambda function.

    The AWS Parameters and Secrets Lambda Extension is an AWS-managed Lambda layer that provides a local, in-memory cache for parameters from AWS Systems Manager Parameter Store and secrets from AWS Secrets Manager.

    • This extension provides built-in caching(default TTL is 300 seconds) and reduces the complexity of managing API calls.
    • However, it may slightly increase cold start times due to extension initialization.
    • You need to ensure that the extension is ready before fetching the secret, possibly implementing a retry mechanism, otherwise you may encounter errors like HTTP Error 400: Bad Request.

    Read more about how Lambda execution environment gets initialized here.

    Adding the extension to your Lambda function:

    • The extension is available both X86_64 and ARM64 architectures. You can find the layer ARNs here.
    class MyCDKStack(Stack):

    def __init__(self, scope: Construct, construct_id: str, **kwargs) -> None:
        super().__init__(scope, construct_id, **kwargs)

        # Add AWS parameters and secrets Lambda extension to read secrets from Secrets Manager
        # ref: <https://docs.aws.amazon.com/secretsmanager/latest/userguide/retrieving-secrets_lambda.html>
        # ref: <https://docs.aws.amazon.com/lambda/latest/dg/with-secrets-manager.html>
        secrets_manager_lambda_extension_layer = _lambda.LayerVersion.from_layer_version_arn(
            self,
            id="SecretsManagerExtensionLayer",
            layer_version_arn=f"arn:aws:lambda:{self.region}:345057560386:layer:AWS-Parameters-and-Secrets-Lambda-Extension-Arm64:23",
        )
        # ^^^I found the layer ARN here from the AWS docs:
        # <https://docs.aws.amazon.com/systems-manager/latest/userguide/ps-integration-lambda-extensions.html#ps-integration-lambda-extensions-add>

        # Create the Lambda function
        my_lambda = _lambda.Function(
            self,
            id="MyLambdaFunction",
            function_name="my-lambda-function",
            runtime=_lambda.Runtime.PYTHON_3_12,
            architecture=_lambda.Architecture.ARM_64,
            ...
            layers=[secrets_manager_lambda_extension_layer],  # Add the extension layer
            ...
        )

    Usage:

    import os
import urllib.request
import json

# ref: <https://docs.aws.amazon.com/systems-manager/latest/userguide/ps-integration-lambda-extensions.html>
def get_secret_from_extension(secret_name: str) -> str:
    """Retrieves a secret value from the Secrets Manager extension."""
    # The extension runs on localhost port 2773 by default
    extension_routing_port: str = os.getenv("AWS_LAMBDA_RUNTIME_API_PORT", "2773")

    # AWS_SESSION_TOKEN is required for authentication with the extension with the Secrets Manager
    aws_session_auth_token: str = os.environ["AWS_SESSION_TOKEN"]

    endpoint = f"<http://localhost>:{extension_routing_port}/secretsmanager/get?secretId={secret_name}"

    # Use the session token to authenticate with the extension
    req = urllib.request.Request(url=endpoint)
    req.add_header("X-Aws-Parameters-Secrets-Token", aws_session_auth_token)

    # Request/Respone Syntax: <https://docs.aws.amazon.com/secretsmanager/latest/apireference/API_GetSecretValue.html>
    with urllib.request.urlopen(req) as response:
        secret_response = response.read().decode("utf-8")
        # The response is a JSON string containing the secret value
        secret_data = json.loads(secret_response)
        return secret_data["SecretString"]

CACHED_SECRET: str | None = None

def lambda_handler(event, context):
    global CACHED_SECRET
    if CACHED_SECRET is None:
        CACHED_SECRET = get_secret_from_extension(secret_name=os.environ["SUPER_SECRET_API_KEY_NAME"])
        os.environ["MY_API_KEY"] = CACHED_SECRET
        # ^^^We are fetching the secret inside the lambda_handler to ensure the extension is fully initialized and ready.
        # Accessing the secret outside the handler function (during module import) can lead to issues because the extension might not be ready yet.

    # ... DO STUFF WITH THE SECRET ...

    return {
        'statusCode': 200,
        'body': json.dumps('Secret retrieved and used successfully!')
    }

  3. Using the aws-lambda-powertools Parameters utility to fetch secrets.

    • This utility provides built-in caching and simplifies secret retrieval.
    • However, it adds an additional dependency to your Lambda function, if you are okay with that.
    • The Parameters utility has other functionalities as well and integrates with other AWS services like SSM Parameter Store, AppConfig along with Secrets Manager.
    from aws_lambda_powertools import Logger
from aws_lambda_powertools.utilities import parameters

logger = Logger()

def lambda_handler(event, context):
    try:
        # Get secret with caching (default TTL: 5 seconds)
        secret_value = parameters.get_secret("my-app/super-secret-api-key")

        # Get secret with custom TTL
        secret_with_ttl = parameters.get_secret("my-app/super-secret-api-key", max_age=300)

        # Get secret and transform JSON
        secret_json = parameters.get_secret("my-app/super-secret-api-key", transform="json")

        logger.info("Successfully retrieved secrets")

        return {
            'statusCode': 200,
            'body': 'Successfully retrieved secrets'
        }

    except Exception as e:
        logger.error(f"Error retrieving secret: {str(e)}")
        return {
            'statusCode': 500,
            'body': f'Error: {str(e)}'
        }

AWS SSM Parameter Store

AWS Systems Manager helps you manage, configure, and operate your compute resources and applications without logging into them.

It lets you:

One of the services provided by SSM is Parameter Store, which allows you to securely store app configs and secrets like API keys, database connection strings, and other sensitive information.

Pricing

AWS Systems Manager Parameter Store consists of standard and advanced parameters.

A Parameter Store API interaction is defined as an interaction between an API request and an individual parameter. For example, if a Get request returns ten parameters, that counts as ten Parameter Store API interactions.

There is also a Intelligent Tier that automatically moves parameters between standard and advanced tiers based on usage patterns.

SSM Parameter Store

You can read more about SSM Parameter Store in the official docs.

Setting up SSM Parameter Store in CDK

CloudFormation (AWS::SSM::Parameter) does not support creating SecureString parameters. Therefore, CDK cannot create SecureString directly.

Recommended option:

Example CDK referencing an existing SecureString and granting read to a Lambda:

import aws_cdk as cdk
from aws_cdk import (
    Stack,
    aws_lambda as _lambda,
    aws_ssm as ssm,
)
from constructs import Construct

class MyCDKStack(Stack):
    def __init__(self, scope: Construct, construct_id: str, **kwargs) -> None:
        super().__init__(scope, construct_id, **kwargs)

        # Reference an existing SecureString parameter (created outside CDK)
        secure_param = ssm.StringParameter.from_secure_string_parameter_attributes(
            self,
            id="ExistingSuperSecretParam",
            parameter_name="/my-app/super-secret-api-key",
            # version=1,  # Optional: pin a specific version
        )

        # Lambda that reads the SecureString parameter
        my_lambda = _lambda.Function(
            self,
            id="MyLambdaUsingSSMParam",
            function_name="my-lambda-ssm-param",
            runtime=_lambda.Runtime.PYTHON_3_12,
            architecture=_lambda.Architecture.ARM_64,
            handler="lambda_function.lambda_handler",
            code=_lambda.Code.from_asset("lambda"),
            environment={
                "SUPER_SECRET_PARAM_NAME": "/my-app/super-secret-api-key",
            },
        )

        # Grant read permissions to the Lambda
        secure_param.grant_read(my_lambda)

Accessing SSM SecureString parameters in AWS Lambda

  1. Using boto3:

    import boto3
import json
import os
from botocore.exceptions import ClientError

_CACHED_PARAM: str | None = None

def get_parameter_value(name: str) -> str:
    """Retrieve SecureString from SSM with decryption."""
    client = boto3.client(service_name="ssm", region_name="us-west-2")
    try:
        resp = client.get_parameter(Name=name, WithDecryption=True)
    except ClientError as e:
        raise e

    return resp["Parameter"]["Value"]

def lambda_handler(event, context):
    global _CACHED_PARAM

    if _CACHED_PARAM is None:
        _CACHED_PARAM = get_parameter_value(os.environ["SUPER_SECRET_PARAM_NAME"])
        os.environ["MY_API_KEY"] = _CACHED_PARAM

    # ... use the secret ...

    return {
        "statusCode": 200,
        "body": json.dumps("Parameter retrieved and used successfully!")
    }

  2. Using the AWS Parameters and Secrets Lambda Extension:

    We will use the same managed layer ARN as in the Secrets Manager section (supports both SSM and Secrets).

    import os
import urllib.request
import json

# ref: <https://docs.aws.amazon.com/systems-manager/latest/userguide/ps-integration-lambda-extensions.html>
def get_parameter_from_extension(name: str, decrypt: bool = True) -> str:
    """Retrieve an SSM parameter via the local extension with optional decryption."""
    extension_port: str = os.getenv("AWS_LAMBDA_RUNTIME_API_PORT", "2773")
    aws_session_auth_token: str = os.environ["AWS_SESSION_TOKEN"]

    endpoint = f"<http://localhost>:{extension_port}/systemsmanager/parameters/get?name={name}"
    if decrypt:
        endpoint += "&withDecryption=true"

    req = urllib.request.Request(url=endpoint)
    req.add_header("X-Aws-Parameters-Secrets-Token", aws_session_auth_token)

    with urllib.request.urlopen(req) as response:
        data = json.loads(response.read().decode("utf-8"))
        # Response shape mirrors SSM GetParameter API
        return data["Parameter"]["Value"]

_CACHED_PARAM: str | None = None

def lambda_handler(event, context):
    global _CACHED_PARAM

    if _CACHED_PARAM is None:
        _CACHED_PARAM = get_parameter_from_extension(os.environ["SUPER_SECRET_PARAM_NAME"], decrypt=True)
        os.environ["MY_API_KEY"] = _CACHED_PARAM
        # Fetch inside handler to ensure the extension is ready

    # ... use the secret ...

    return {
        "statusCode": 200,
        "body": json.dumps("Parameter retrieved and used successfully!")
    }

  3. Using aws-lambda-powertools Parameters utility:

    from aws_lambda_powertools import Logger
from aws_lambda_powertools.utilities import parameters

logger = Logger()

def lambda_handler(event, context):
    try:
        # Get SecureString with decryption and default caching (TTL 5s)
        secure_value = parameters.get_parameter("/my-app/super-secret-api-key", decrypt=True)

        # Custom TTL
        secure_value_ttl = parameters.get_parameter("/my-app/super-secret-api-key", decrypt=True, max_age=300)

        # Retrieve multiple parameters by path
        params = parameters.get_parameters_by_path("/my-app/", decrypt=True, recursive=True, max_age=300)

        logger.info("Successfully retrieved parameters")
        return {"statusCode": 200, "body": "Successfully retrieved parameters"}

    except Exception as e:
        logger.error(f"Error retrieving parameter: {str(e)}")
        return {"statusCode": 500, "body": f"Error: {str(e)}"}

Notes:

References:

Docs:

Be a Better Dev YT Videos:
