4.5. Artifacts
The CHIME maps are sensitive to structures on a wide range of angular scales. Some artifacts are described in detail in CHIME Collaboration (2022). One is evident in the single diagonal stripe in the top left corner of Figures 2 and 3, which is a line at the right ascension of Tau A. Curved striations, seen in the Stokes Q and U images (Figure 2) and the Faraday synthesis images (Figure 3), correspond to fixed zenith angles (or, equivalently, declinations). Point sources appear as a single point with bright copies at the same declination on either side of the source due to grating lobes, resulting in an apparent triple source. The sources themselves appear in Stokes Q in equatorial coordinates due to leakage, with symmetric sidelobes, while in Stokes U only the asymmetric sidelobes, with opposite signs, appear. In the Galactic coordinates shown in this paper, leakage sources appear in both Q and U, along with their sidelobes.
Grating lobes also appear for larger-scale structures, having a slight effect on the appearance of the images of the tadpole region. In the CHIME 410 MHz pI map in Figure 5, a copy of the head of the tadpole can be seen as an outline that stands out in polarized intensity, centered on ℓ ≈ 138.5◦ , b ≈ 8.5◦ . The location and the separation between this and the center of the head agrees with the position of the grating lobes in relation to the main lobes of the point sources. This ‘ghost’ copy of the tadpole also appears in the 410 MHz polarization angle image in Figure 5, is generally more apparent at the lower frequencies, and is quite evident in the Faraday depth slices shown in Figure 6.
There is also declination-dependent striping, which appears as curved stripes in Galactic coordinates in Figure 2 and other images, although it is much less pronounced in angle images and Faraday synthesis products. This arises from cross talk between adjacent feeds (CHIME Collaboration 2022, Figure 18). We could remove the striping using image processing techniques, but this cosmetic improvement to the images is unnecessary for our science. Ultimately, the inclusion of the DRAO 15 m survey (Ordog et al in prep) will allow us to exclude baselines ≲ 5 m from the final CHIME-GMIMS data product; we expect this to considerably reduce this striping.
