THE LOCOMOTIVE

UNCLE PAUL showed his nephews the following picture, and explained it to them. An old-time Locomotive “This picture represents a locomotive. The boiler where the steam is generated, the boiling pot, in short, forms the greater part of it. It is the large cylinder that goes from one end to the other, borne on six wheels. It is built of solid iron plates, perfectly joined together with large rivets. In front the boiler terminates in a smoke-stack; behind, in a furnace, the door of which is represented as open. A man, called a stoker, is constantly occupied in filling the furnace with pit-coal, which he throws in by the shovelful; for he must keep up a very hot fire to heat the volume of water contained in the boiler and obtain steam in sufficient quantity. With an iron bar he pokes the fire, arranges it, makes it burn fast. That is not all: skilful arrangements are made to utilize the heat and warm the water quickly. From the end of the furnace start numerous copper pipes which traverse the water from one end to the other of the boiler, and terminate at the smoke-stack. You will see some in B where the picture supposes a part of the casing taken away to show the interior. The flame of the furnace runs through these pipes, themselves surrounded by water. By this means the fire is made to circulate through the very midst of the water, and so steam is obtained very quickly.
