TLDR: Trying to optimize JSON queries in MYSQL, make use of stored generated columns

Ran into a situation where I had a table with loads and loads of records that included a meta JSON column, ideally the fields in the JSON column were queried using JSON_EXTRACT

models.sequelize.where(
  models.sequelize.fn(
      'JSON_EXTRACT', models.sequelize.col('meta'), models.sequelize.literal('$.type')
  ),
  Op.eq,
  query.type
)

JSON columns are useful for flexible data models, but they have limitations; queries on JSON fields can’t make use of indexes. As the number of records increased, the limitations of not being able to index a JSON column began to become apparent, and queries started to become considerably slower.

STORED GENERATED COLUMN

A generated column in MySQL is a column where the values are computed from the values of other columns in the same row. A generated column can be either virtual or stored

Virtual column - Data is computed every time the data is queried; data isn’t stored in the DB
Stored generated column - Data is computed when the source columns are created/updated and stored on disk, similar to how a normal column would be stored

Virtual Column vs Stored-generated column

	Virtual column	Stored Generated column
Can query against	Yes	Yes
Can index	No	Yes
Uses a lot of space	No	Yes
Columns are stored physically	No	Yes
Automatic updates	No, data is re-computed every time the column is queried	Yes, the column is updated automatically
Created or updated directly	No	No

Migration

await queryInterface.sequelize.query(`
   ALTER TABLE customer ADD COLUMN type VARCHAR(30)
    AS (JSON_UNQUOTE(JSON_EXTRACT(meta, '$.type'))) STORED,
   ADD INDEX type_idx (type); `);

This migration script adds a type column to the customer table, it then tells MySQL to compute the value by extracting it from the meta.type and store STORED as a generated column. ADD INDEX type_idx (type) adds an index on the field to allow for faster queries

Benefits

Columns are indexable
Queries are faster than querying JSON columns
You can query against the stored column as you’d query any other column

Cons

Makes use of a little more space but as someone I know would say SPACE IS CHEAP

Conclusion
